The stabilizer link / sway bar link Consists of a connecting rod and a ball head. The ball head is composed of a ball seat, a ball pin, a plastic nut, a O-shaped snap ring, a dust cover and a O-shaped tie ring. The ball seat is equipped with a ball pin; the ball pin is covered with a dust cover , The bottom of the dust cover is connected to the ball seat through a C-shaped beam ring, the ball seat is in the shape of a drop, a connecting hole is provided on one side of the ball seat, and an assembly hole corresponding to the ball pin is provided on the ball seat.
Item NO.:
5087.48Order(MOQ):
50Payment:
TT, LC, PAYPALProduct Origin:
CHINAColor:
OEM STANDARDShipping Port:
SHANGHAI OR NINGBOLead Time：
30 DAYS31351134582 BMW front axle stabilizer bar link
The function of stabilizer links:
When the left and right wheels travel through the same bumps or holes on the road, the balance bar will not work. However, if the left and right wheels pass through different road bumps or holes, that is, when the level of the left and right wheels are different, it will cause the shaft to twist and produce anti-roll resistance (Roll Resistance) to inhibit the rolling of the body. That is to say, the balance bar will not work when the left and right suspensions move synchronously up and down, and the balance bar will only work when the left and right suspensions move out of sync due to road undulations or turning and cornering.
OE NUMBER:
5087.48
5087.60
5087.43
96324274
APPLICATION CAR:
CITROEN C5 II 2004-
PEUGEOT 406 2000-2004
PEUGEOT 607 2000-2011
SIZE: LENGTH 322 MM
THREAD SIZE: M12*P1.75mm
FITTING POSITION: Front Axle Right and Left
MATERIAL: Ball Shell Use 45 Steel,Ball Pin Use 40 Cr With Heat Treatment Surface.
HARDNESS : 28-35.
GREASE : Gread A,GB/T7324-2010,(-40℃ - 120℃).
Rubber Is Use The Best Material Work On -40℃-120℃
WARRANTY: 2 years
ACCEPTED OEM SERVICE： YES
MOQ: 50pcs
PACKAGE: Plastic bag+ Carton + Pallet or According to our customer's request
LOGO: Laser marking our customer's LOGO on the products
DELIVERY TIME: 30 DAYS, If new model, it will be 45 days.
WHY CHOOSE US?
Ningguo Friend Trading Co., Ltd has around more than 600 kinds of stabilizer links. And we have professional techanical department. So that we can make the sample according to your samples or drawings within 10 days.
Our stabilizer links have been exported to Mexico, Russia, USA, ITALY, Germany, Canada, South Africa.
We have very strictly quality controlling system to make sure each stabilizer link with good quality standard. If any quality problem , we will send the high quality products to you freely again.
FAQ:
1. Q: How about your Quality Controlling System?
A: Each step of our production process have the quality checking workers. They will check the products one by one before going to next production step. And before package, our QC workers will choose 15% of the cargo to check the quality again to make sure the cargo is with good quality. If the 15% products have around 1% with defects, we will recheck all pieces of the cargo. And our quality warranty is 2 years. If any quality issues feedback from our customers, we will fully take charge of it.
2. Q: How long is your delivery term?
A: Our standard product delivery term is normally 30 days.
A new product development is 60days including the mass production. Under normal circumstances there are standing stock for regular types.You can email us to learn more details.
3. Q: How many years is your company in auto parts business field?
A: Our Company started since 2005,there is about 16 years history forus in auto parts business field.
4. Q: Are you trading company or factory?
A: We are factory with trading company.
5. Q:What's the MOQ for each item?
A: Our business way is spot sales,if the items we have stock,there is no limitation for MOQ to be manufactured based on your order.
